FEATURES
• Utilizes AutoSense™ Technology to monitor your water usage and determine the optimal frequency of regeneration, minimizing salt and water use
• High-flow valve for optimal water pressure
• Utilizes reverse flow regeneration, proven to be the most effective way to clean the resin bed
• Ideal for small to medium households
• Can be used with city or well water sources
• Installation kit includes custom fit bypass valve
SPECIFICATIONS
| Model Number: NST30ED |
| Part Number: 7366431 |
| Household Size: 1-5 people |
| Max Capacity (grains): 30,200 |
| Resin(cu. ft): 0.78 |
| Standard Connection Size: 1" NPT |
| Valve: 3/4" valve; up to 1" plumbing |
| Connection Size: 1" male pipe thread |
| Rated Service Flow Rate (gpm): 7.3 |
| Intermittent Flow Rate (gpm @ 30 psi drop): 11 |
| Clear Water Iron Removal (ppm): 8 |
| Electric Demand: Yes |
| Max. Efficiency (per minimum salt dose): 5,090 @ 2.3 lbs |
| Dimensions: Resin Tank and Electronics H 48 3/4" X W 11 1/2" Brine Tank H 39" X W 18" |
| NSF Certification (NSF/ANSI standard): 44 & 372 |
| Warranty : 1 year parts | 3 year electronic control board | 10 year salt storage and mineral tank |
